LUVOCOM 3F PAHT 9825 NT (1.75mm 500 gram)
Pickup available at 7A Kent Street, Yarraville, VIC
Usually ready in 4 hours
7A Kent Street, Yarraville, VIC
7A Kent Street
Yarraville VIC 3013
03 9687 8638
FormFutura Luvocom 3F PEKK 50082 (PolyEtherKetoneKetone) is a high-performance polymer from the PAEK (PolyArylEtherKetone) family. Luvocom 3F PEKK 50082 is a semi-crystalline PEKK filament which exhibits outstanding mechaniccal properties combined with excellent thermal-, wear-, and chemical resistance. Parts that are 3D printed with Luvocom 3F PEKK 50082 filament are suitable for use in applications that will be exposed to short term service temperatures of up to 300°C and continious service temperatures up to 255°C.
FormFutura Luvocom 3F PEKK 50082 filament can be processed at lower 3D printing temperatures than PEEK-based 3D printer filaments and yet it provides approximately a 15°C higher glass transition temperature (Tg). This makes Luvocom 3F PEKK 50082 filament a very versatile high performance 3D printing polymer that is capable to 3D print parts that can replace metal and composite parts used in various industries. This PEKK filament unlocks industrial 3D printing applications in various industries, such as aerospace, medical, oil & gas, energy, marine, and automotive. Luvocom 3F PEKK 50082 filament allows one to 3D print parts with excellent layer bonding resulting in an usnurpassed dimensional accuracy and z-strength for PEKK 3D printed parts.
- Lehvoss Luvocom 3F PEKK 50082 NT inside
- Suitable for applications with a continuous service temperature of 255°C
- Short term service temperature of 300°C (during lifetime max. 200h)
- Very limited to no warping
- Unique tribological properties
- Excellent mechanical properties
- Flame resistance properties according to UL 94 V-0
- Exceptional chemical resistance properties
- Dynamically-stressed parts
- Highly chemically-resistant parts
- Wear resistant parts
- Aerospace applications
The PAEK family
PolyArylEtherKetone (PEAK) is a family of semi-crystalline high performance thermoplastics that are characterized by high mechanical strength and excellent resistance to temperature, chemicals and wear.
The most widely used members of the PAEK thermoplastic family are:
- PolyEtherEtherKetone (PEEK)
- PolyEtherKetoneKetone (PEKK)
- PolyEtherKetone (PEK)
- PolyEtherKetoneEtherKetoneKetone (PEKEKK)
- PolyEtherEtherKetoneKetone (PEEKK)
General printing guidelines *
|Nozzle size: ≥ 0.4mm||Layer height: ≥ 0.10mm||Experience level: Expert|
|Print temp: ± 320 – 360° C||Fan speed: 0 – 25%||Drying: +4 hours at max.110°C|
|Heat bed: ≥ 120° C||
Enclosure needed: 90°C heated chamber
||Adhesion: EasyFix Nr. VII|
*) Above displayed settings are meant as guidance to find your optimal print settings. These ranges in settings should work for most printers, but please do feel free to experiment outside these parameters if you think it is suitable for your printer. There are a lot of different type of printers, hot-ends and printer offset that it is extremely difficult to give an overall one-size-fits-all setting.
|ρ: 1.27 g/cc||0.2 Kg spool||0.5 Kg spool|
|Ø 1.75mm||± 65m||± 164m|
|Ø 2.85mm||± 25m||± 62m|
Product export information
|HS Code: 39169090||Description: Monofilament||Country of origin: the Netherlands|
This filament is compliant to below-listed directives and regulations.
- RoHS directive 2011/65/EC
- REACH directive 1907/2006/EC
*) This declaration of conformity to directives and regulations is prepared according to our present standard of knowledge and may be amended if new cognitions are available and applies only for the above-described products.
