Bambu 4-in-1 PTFE Adapter

Zoom

Out stock

Bambu 4-in-1 PTFE Adapter

Name: Bambu 4-in-1 PTFE Adapter
Brand: Bambu Lab
SKU: FAZ013-N
Price: 9.99 AUD
Availability: InStock

The Bambu 4-in-1 PTFE Adapter is an adapter used to connect the PTFE tube. Compared to the original PTFE tube connector, the 4-in-1 adapter can connect 4 feeder modules to the printer at the same time.

$9.99

Printer Compatibility :X1 Series /P1 Series/ H2D/ H2S/ P2S

X1 Series /P1 Series/ H2D/ H2S/ P2S

H2C/ H2C Laser

Quantity

SKU: FAZ013-N

VENDOR: Bambu Lab

Pickup available at 7A Kent Street, Yarraville, VIC.

Usually ready in 4 hours if in stock

PRODUCT INFORMATION

Overview

For X1 Series/P1 Series/H2D/H2S/P2S

It can help users to connect the printer to AMS along with other filaments which are not compatible with AMS such as TPU 95A, Bambu PET-CF and other brands' carbon-fiber/glass-fiber contained filaments.

For H2C

The 4-in-1 PTFE Adapter can simultaneously connect four filament input modules to the printer, enabling up to 7 color of filament printing. It also allows the printer to connect both to the AMS and to filaments that are not compatible with the AMS, such as TPU95A, Ta Zhu PET-CF, and other carbon fiber or glass fiber-containing filaments.

Installation

For X1 Series/P1 Series/H2D/H2S/P2S

Learn more about the replacement of Bambu 4-in-1 PTFE Adapter on

Bambu Lab Wiki

For H2C

Learn more about the replacement of Bambu 4-in-1 PTFE Adapter on Bambu Lab Wiki.

Compatibility

X1 Series/P1 Series/H2D/H2S/P2S

H2C and H2C Laser

In the Box

For X1 Series/P1 Series/H2D/H2S/P2S

Bambu 4-in-1 PTFE Adapter *1

For H2C

Bambu 4-in-1 PTFE Adapter *1

Bambu 4-in-1 PTFE Adapter Filament II Cleaning Pad *5

Instructions for use

The Bambu 4-in-1 PTFE Adapter is designed with a clear direction of use, as shown in the figure below.

1. When using AMS:

- Connect the PTFE tube from the tool head to the OUT end of the Bambu 4-in-1 PTFE Adapter.
- Connect the PTFE tube from the buffer output to one of its IN ends. - Directly insert a maximum of three filament wires into each hole of the Bambu 4-in-1 PTFE Adapter IN end.

2. When the AMS is not being used:

- Connect the PTFE tube from the tool head to the OUT end of the Bambu 4-in-1 PTFE Adapter.
- Directly insert a maximum of four filament wires into each hole of the Bambu 4-in-1 PTFE Adapter IN end.

It is important to note that reversing connections may cause filament blockage. Therefore, it is essential to ensure that the installation direction is correct.

Product Specification

Color	Black, White	Materials	Plastic, Metal
Package weight	0.03 kg	Package Size	606030 mm
